Fusion Flat panel series

Look up on the side and rear walls of a large cinema and you will often see flat panel type speakers. Here is a range of home theatre rear, surround or even front main speakers that can be used in a similar wall hugging fashion. In no way has the performance of these speakers been compromised, they are all exceptionally clear and accurate performers, adding the realism to movies or music you would expect from a high quality speaker, and drawing you into the experience.

Flat Panel F612PV
6" 2-way medium size

Price: $650/pr (or $350 kit less cabinet)
Finish: Natural semi-gloss finished American oak veneer.  Or, the American oak can first be stained light oak, European oak, walnut, dark walnut, jarrah, rose mahogany, or black. Also, semi-gloss black or white without veneer. Natural semi-gloss blackwood veneer is a little extra. See veneers and finishes page.
Cabinet: 400h x 300w x 160d side bass reflex 10 litres
Power Handling: 80/160 wrms/wmax @ 80 Hz crossover to subwoofer
Nominal Impedance: 8 ohms
Frequency Response: 58 -- 35,000 Hertz +/-2dB
Sensitivity: 90dB 1w/1m
Drivers: Peerless 180 mm bass/midrange driver;high efficiency 26 mm soft dome tweeter.
Description: This is a  high resolution critical listening speaker for any purpose, in a small package. For people who want the best sound in an economical wall-hugging surround speaker system, or high level stereo bookshelf speaker. Ribbon tweeter version extra $100.

Flat Panel F502PV
5" 2-way small size

Price: $450/pr (or $250 kit less cabinet)
Finish: Natural semi-gloss finished American oak veneer.  Or, the American oak can first be stained light oak, European oak, walnut, dark walnut, jarrah, rose mahogany, or black. Also, semi-gloss black or white without veneer. Natural semi-gloss blackwood veneer is a little extra. See veneers and finishes page.
Cabinet: 300h x 170w x 160d sealed cabinet 4 litres
Power Handling: 80/160 wrms/wmax @ 100 Hz crossover to subwoofer
Nominal Impedance: 8 ohms
Frequency Response: 90 -- 35,000 Hertz +/-2dB
Sensitivity: 90dB 1w/1m
Drivers: Die-cast wool cone 143mm bass/midrange driver; high efficiency 26 mm soft dome tweeter.
Description: This is a smaller sealed cabinet version of the F612PV above. Great full sound and high power for a small satellite of this size. Integrates beautifully with our subwoofers. Suitable for mounting on walls or in small spaces. Ribbon tweeter version extra $100.

Photos show horizontal mounting and vertical


Flat Panel F431FK
  4x 3.5" full range surround array speaker

Price: $795/pr (or $395 kit less cabinet)
Finish: Natural semi-gloss finished American oak veneer.  Or, the American oak can first be stained light oak, European oak, walnut, dark walnut, jarrah, rose mahogany, or black. Also, semi-gloss black or white without veneer. Natural semi-gloss blackwood veneer is a little extra. See veneers and finishes page.
Cabinet: 160h x 800w x 160d sealed box 10 litres
Power Handling: 75/150 wrms/wmax @ 80 Hz crossover to subwoofer
Nominal Impedance: 8 ohms
Frequency Response: 80 -- 30,000 Hertz +/-2dB
Sensitivity: 90dB 1w/1m
Drivers: 4 x 85mm wide range drivers; 3 x 25mm dome tweeters
Description: This is a new and unique diffuse surround speaker design for home use that takes its design cue from true professional surround speakers used in actual cinemas, where  four or six speakers all projecting the same signal are lined along the side walls to give a diffuse surround effect that does not indicate the direction of the source. This effect is necessary for rain storms, background sounds etc., as used in movies for ambient effects.  The F63FK surround array arranges four small wide range drivers and three tweeters in a single, conveniently sized long thin speaker that can be easily mounted on the side walls to create this effect.  (Of course, in larger rooms, four of the F502PS model speakers above could be used on the side walls instead, in exactly the same manner they do at the cinema.)

Other surround array versions, phone for details. F451ST

F441PS

Flat Panel F452FR
4 x 5" 2-way large multi-use wall speaker or centre

Price: $595 each ($395 each kit) or $1095pr ($695pr kit)
Finish: Natural semi-gloss finished American oak veneer.  Or, the American oak can first be stained light oak, European oak, walnut, dark walnut, jarrah, rose mahogany, or black. Also, semi-gloss black or white without veneer. Natural semi-gloss blackwood veneer is a little extra. See veneers and finishes page.
Cabinet: 800 x 300h x 160d bass reflex 24 litres
Power Handling: 200 wrms
Nominal Impedance: 8 ohms
Frequency Response: 56 -- 30,000 Hertz +/-2dB
Sensitivity: 92dB 1w/1m
Drivers: 4 x 5 inch nominal wool cone bass/mid; Superb high efficiency true ribbon tweeter.
Description: This speaker uses the superb clarity, efficiency and fast response of our versatile woofer/mid married with one of our better tweeters. This speaker is primarily a wall hugging centre, but has a multi uses and a very natural and even response. It is essentially the same as the Quartet 452FS centre, only the cabinet dimensions have been changed to suit a wall hugging flat panel use. Suitable all-round in a high end home theatre system as a horizontal wall mounted centre or vertical front speakers with smaller flat panel surrounds (e.g. F612PV or F502FV), or just as the surround speakers in a system with large floorstanding fronts (e.g. Summoner 1093 or Timberwolf 8883). Ribbon tweeter can be rotated for vertical use. $50 less, each, if soft dome tweeter preferred.



Ribbon tweeter upgrade

Flat Panel F6632SR
double 6" 2-way medium floorstander or wall speaker

Price: $1350/pr (or $850 kit less cabinet)
Finish: Natural semi-gloss finished American oak veneer.  Or, the American oak can first be stained light oak, European oak, walnut, dark walnut, jarrah, rose mahogany, or black. Also, semi-gloss black or white without veneer. Natural semi-gloss blackwood veneer is a little extra. See veneers and finishes page.
Cabinet: 900h x 300w x 210d  bass reflex 36 litres
Power Handling: 140 wrms
Nominal Impedance: 8 ohms
Frequency Response: 37 -- 40,000 Hertz +/-2dB
Sensitivity: 92dB 1w/1m
Drivers: 2 x 171 mm papyrus cone high end SB Acoustics bass/midrange drivers; high efficiency true ribbon tweeter.
Description: This SB Acoustics dual 6 inch speaker is a true high grade performer with beautiful, smooth detail through the whole sound spectrum. This floorstander model has been designed to allow you to place it against a wall to save space, or for use with a projection screen, and so on, there are many uses for a speaker like this. All our SB Acoustics drivers have exceptional quality extended bass and smooth midrange in our unique designs, and this is no exception. Add a balanced, smooth and natural treble from the wide dispersion and airy ribbon tweeter, and you have the sort of sound that is a joy to the ears. Highly recommended as a practical large front/rear/surround speaker in a large room powerful system. Ribbon tweeter now is standard.


3-way version using the Summoner 843 design with ribbon option

Custom F2103PMTL
large high power double 10" flat panel wall speaker

Home Theatre Suggestions

Here are some suggestions for home theatre setups taken from our range of models that would work well as a combination, keeping in mind that there are many other combinations possible depending on your circumstances. Feel free to call if you have any particular combinations in mind (model codes may vary slightly).
